The CNC Router MTM-1325 is an excellent choice for you to get the job done just the way you like. It is furnished with superb features. Its ravelling speed can be up to 20m/min, and it is configured with the professional CNC controlling system. It can be compared with professional with various CAD/CAM software as TYPE3 / Artcam / Castmate / caxa / Artcut and many others.
It can highly support G-code and IJK code, and CNC Router MTM-1325 has its own functions of restoring from power off, the continuation from a breakpoint, auto feeding blades, repeat engraving, and support nine coordinate positionings. It is Standard with Taiwan LAPPING linear rail to ensure more accuracy 3kw water cooling spindle motor standard and it is also a powerful YAKO driver board with a high power inverter to make the machine stronger. The optional vacuum system and dust collector system can be added.
Aerospace technology, rocket, plane, robot, surgical equipment elevator, steamship and automobile manufacturing and metal parts processing industry for metal plate, advertisement, kitchen ware, bit tool, hardware and more.
CNC Router MTM-1325 Applications:
CK1325 series has a strong function with good performance, easy to use, solid and durable. This series applied extensively in MDF, wood, advertising, plastic, aluminum, engraving board, engineering plastics, marble, acrylic, perspex, PVC, composite materials, and more.
| PARTS NAME | DESCRIPTION | |
| Rail: | Configure with Taiwan LAPPING Linear Rail | |
| Package Size: | 3180*1980*1800mm; | |
| Gross Weight: | 1280KGS | |
| X, Y Working Area: | 1300x2500mm, machine transmitting by rack and gear | |
| Z Working Area: | 150mm-200mm | |
| Max. Speeding: | 20m/min | |
| Work-Holding: | Standard with a wide and hard aluminum table with high quality clamps (vacuum system with 7.5KW vacuum pump is optional) | |
| Processor: | Adopt the most advanced FPGA LCM controlling system | |
| Spindle Motor Power: | 3KW water cooling spindle motor | |
| Surroundings for Software: | Windows10/7/XP | |
| Power (Spindle is not included) | 3000W | |
| Collet: | ER20 (Φ3.175, Φ6 standard) | |
| Working Voltage: | AC220V/50HZ/60HZ for the standard machine, if an optional vacuum system or servo system, it needs 380V 3 phase | |
| Main Axis Rotating Speed: | 0-24000rpm/min | |
| Work Mode: | Large stepper motors and drivers; Servo Motor (Optional) | |
| Control Mode: | Handle control | |
| Engraving Tools & Collets: | 3.175mm; 6mm; 12.7mm; (sending you 10 pcs with the machine). 2 collets standard with the machine | |
| Software: | New version type3 software: Router 8 | |
| Warranty: | One year without the tools | |
| Optional: | the CNC Router MTM-1325 has the dust collector system; Vacuum system with a Chinese vacuum pump or Germany pump; Servo system |
